G070ACE-LH1 7" Ultra High Brightness 1000cd/m2 TFT LCD | 800x480 IPS Industrial Display - Wholesale

G070ACE-LH1 7` Ultra High Brightness 1000cd/m2 TFT LCD
G070ACE-LH1 7` Ultra High Brightness 1000cd/m2 TFT LCD
  • G070ACE-LH1 7` Ultra High Brightness 1000cd/m2 TFT LCD
  • G070ACE-LH1 7` Ultra High Brightness 1000cd/m2 TFT LCD

G070ACE-LH1 7" Ultra High Brightness 1000cd/m2 TFT LCD | 800x480 IPS Industrial Display - Wholesale

1000nits High Brightness Innolux G070ACE-LH1 7inch IPS TFT LCD 800x480 WVGA, LVDS interface, Sunlight-readable for outdoor industrial equipment Factory-direct wholesale with MOQ 1pcs DDP shipping & samples available!

Model G070ACE-LH1
Brand INNOLUX
Size 7.0inch
Resolution 800*480
Brightness 1000cd/m2
Perspective 89/89/89/89
Interface LVDS
Operating Temp -30 ~ 80 °C
Production State In Production
Click For Price

1.INNOLUX 7" Ultra High Brightness LCD G070ACE-LH1 Application Details

Basic Info :Panel BrandAUOPanel ModelG070ACE-LH1
Diagonal Size7.0inchApplicationIndustrial,Outdoor High Brightness
Panel Typea-Si TFT-LCD , LCM

Reliability :Operating Temp.-30 ~ 80 °CStorage Temp.-30 ~ 85°C
RoHS StateRoHSVibration Level1.5G (14.7 m/s²)
Specific Features :Wide Temperature，Ultra High Brightness,WLED Backlight，Life>=50 hours,With LED Driver,6/8 bit,,Matte



2.INNOLUX 7" Ultra High Brightness LCD G070ACE-LH1 Mechanical Details

Pixel Features :Pixel Format800(RGB)*480, WVGADot Pitch (W*H)0.0635*0.1905 mm
ConfigurationRGB Vertical StripePixel Pitch (mm)0.1905*0.1905 mm  [133PPI]
Mechanical Size :Active Viewing152.4(W)*91.44(H) mmOverall Dim.170(W)*110(H) mm
Bezel Opening154.4(W)*93.44(H) mmOverall Depth6.0/8.85 (Typ./Max.) mm
Outline Features :Form FactorFlat RectangleOrientationLandscape type
Aspect Ratio15:9 (H:V)Shape Style
Fixation : Side mounting holes (4-M2) on up, down bezel
Other Detail :Mass183±9gSurfaceAntiglare, Hard coating (3H)


3.INNOLUX 7" Ultra High Brightness LCD G070ACE-LH1 Optical Details

BrightnessBrightness1000 cd/m²  (Typ.)Contrast Ratio800:1 (Typ.) (Transmissive)
Viewing Angle89/89/89/89(Typ.)(CR≥10) Optical ModeAAS, Normally Black, Transmissive
Viewing DirectionSymmetryResponse Time13/12 (Typ.)(Tr/Td)
Color Performance :ChromaticityWx:0.313; Wy:0.329Color Numbers262K/16.7M (6-bit / 8-bit)
Color Temperature6485KUniformity1.43 (Max.)(5 points)
1931 Color Gamut :NTSC Ratio59%sRGB82% coverage
Adobe RGB62% coverageDCI-P361% coverage
Rec.202044% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :Outdoor VisibilitySunlight ReadableTransmissivity-


4.INNOLUX 7" Ultra High Brightness LCD G070ACE-LH1 Electronics Details

Frame Frequency :60Hz
Reverse Scan :No
Time Controller (T-CON) :3.98W (Typ.)


5.INNOLUX 7" Ultra High Brightness LCD G070ACE-LH1 Backlight Details

Back-light Features :Lamp TypeWLEDAmount-Life Time50K(Min.) (Hours)
Replacement-Lamp Shape-PositionEdge light type
Interface Features :Position
 		-Physical TypeIncluded in signal interface
Backlight Driver :With LED Driver
Backlight Driver :Input Current0.3±0.1AInput Voltage12.0±1.2V
Consumption3.5/4.0W (Typ./Max.)


6.INNOLUX 7" Ultra High Brightness LCD G070ACE-LH1 Interface Details

Signal Electrical :Input Current135/200mA (Typ./Max.)Input Voltage3.3V (Typ.)
Consumption
 		0.48/0.73W (Typ./Max.)Signal InterfaceLVDS (1 ch, 6/8-bit)
Interface Features :Position-TypeConnector
Signal Interface :BrandModelAmountPin PitchPin AmountPin Assignment
STARCONN093G30-B0001A-G41 pcs1.0mm30pins


7.Innolux 7" Ultra High Brightness LCD G070ACE-LH1 Packing Details

Package Box :QuantityWeightBox Size
38 pcs / box8.3Kgs455*370*275 mm (L*W*H)

Post A Message

Your email address will not be published. Required fields are marked *

Name*
Your E-Mail*
Message*
G070ACE-L01 7" IPS TFT LCD | Industrial 800x480 Display - OEM/ODM Wholesale G070ACE-LH2 INNOLUX 7" Industrial TFT LCD | IPS 800x480 Wholesale | Global Stock

Related Products

G070ACE-LH2 INNOLUX 7" Industrial...

G070ACE-LH2 INNOLUX 7" Indu...

G070ACE-LH3 INNOLUX 7" Industria...
