Innolux G121S1-L02 12.1 "IPS Industrial Screen | 800 × 600 | A-grade Original | Wide Temperature Design

G121S1-L02
G121S1-L02
  • G121S1-L02
  • G121S1-L02

Innolux G121S1-L02 12.1 "IPS Industrial Screen | 800 × 600 | A-grade Original | Wide Temperature Design

Qimei original A-class G121S1-L02 12.1-inch IPS industrial screen, resolution 800 × 600, wide viewing angle, wide temperature operation (-30~80 ℃). Suitable for military, medical, and industrial control equipment, supporting OEM customization and global wholesale.

Model G121S1-L02
Brand Chimei Innolux
Size 12.1inch
Resolution 800*600
Brightness 600 cd/m² (Typ.)
Perspective 89/89/89/89
Interface LVDS
Operating Temp -30 ~ 80 °C
Production State Discontinued
Click For Price

1.Chimei Innolux  G121S1-L02 Application Details

Basic Detail :Panel BrandINNOLUX/CHI MEIModel Name G121S1-L02
Panel Typea-Si TFT-LCD , LCMAnother Name
Panel Size12.1”Designed ForIndustrial,Automotive Display
Maximum Ratings :OP Temperature-30 ~ 80  °CST Temperature-30 ~ 85  °C
RoHSRoHSVibration Level1.5G (14.7 m/s²)
Features :Wide Temperature，Hight Brightness,Lamp Repaceable, WLED Backlight，Life>=50K hours,With LED Driver, U/D,L/R Reverse,6/8 bit, Matte


2.Chimei Innolux   G121S1-L02 Optical Details

Basic Information :Luminance600 cd/m²(Typ.)Contrast Ratio1500:1 (Typ.) (Transmissive)
Good View atSymmetryResponse Speed13/12 (Typ.)(Tr/Td) (ms)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)Operating ModeSuper MVA, Normally Black, Transmissive
Color Performance :ChromaticityWx:0.313; Wy:0.329Display Colors262K/16.2M (6-bit / 6-bit + FRC)
Color Temperature6485KWhite Variation1.25/1.40 (Typ./Max.)(9 points)
1931 Color Gamlt :NTSC Ratio51%sRGB71% coverage
Adobe RGB53% coverageDCI-P353% coverage
Rec.202038% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)


3.Chimei Innolux G121S1-L02 Mechanical Details

Pixel Features :Number of Pixel800(RGB)*600 [SVGA]ArrangementRGB Vertical Stripe
Dot Pitch 0.1025*0.3075 mm (H*V)Pixel Pitch 0.3075*0.3075 mm (H*V)  [82PPI]
Physical Size :Active Viewing(mm)246*184.5 mm (H*V)Bezel Area (mm)249.0*187.5 mm (H*V)
Outline Dim.(mm)260.5*204 mm (H*V)Depth(mm)8.4±0.5 mm
Outline Features :Form StyleFlat RectangleOutline Shape
Aspect Ratio4:3(W:H)OrientationLandscape type
Fixation :Side mounting holes (4-M2) on left, right bezel
Other Spec :Weight520/550g (Typ./Max.)SurfaceAntiglare (Haze 22%), Hard coating (3H)


4.Chimei Innolux   G121S1-L02 Electronics Details

Refresh Rate :60Hz
Reverse Scan :Yes (U/D, L/R)
Total Consumption :9.1W (Typ.)


5.Chimei Innolux G121S1-L02 Interface Details

Signal Systerm :LVDS (1 ch, 6/8-bit)Logic Voltage-
Signal Electrical :Voltage Input3.3/5.0V (Typ.)(VCC)Current Input460/310mA (Typ.)(3.3V/5.0V)
Consumption1.52/1.85W (Typ./Max.)(3.3V)
Interface Features :Position-Physical TypeConnector
Interface Detail :BrandModelPin PitchPinsAmountPin Assignment
JAEFI-SEB20P-HFE1.25mm20pins1 pcsLVDS-20P1C8B-150A


6.Chimei Innolux G121S1-L02 Backlight Details

Lamp Features :Lamp TypeWLEDQuantity-PositionEdge light type (Bottom side)
Exchange
 Replaceable		Lamp Shape-Lamp Life50K(Min.) (Hours)
Interface Features :Position-Physical TypeConnector
Interface Detail :BrandModelPin PitchPinsAmountPin Assignment
ACES91208-01001-H011.0 mm10 pins1 pcs
Backlight Driver :With LED Driver
Driver Electrical :Input Voltage12.0±1.2VInput Current0.54A (Typ.)
Consumption6.48W (Typ.)


7.Chimei Innolux G121S1-L02 Carton Details

Package Box :AmountWeightSize (L*W*H)
16pcs / box15 Kgs465*362*314 mm
