New Original TIANMA TM150TDSG81 15" WLED LCD - 1024×768 eDP 350nits Display

Original TIANMA TM150TDSG81 15inch WLED LCD Module
Original TIANMA TM150TDSG81 15inch WLED LCD Module
  • Original TIANMA TM150TDSG81 15inch WLED LCD Module
  • Original TIANMA TM150TDSG81 15inch WLED LCD Module

New Original TIANMA TM150TDSG81 15" WLED LCD - 1024×768 eDP 350nits Display

New Original TIANMA TM150TDSG81 15" WLED LCD Module - 1024×768 resolution, 350nits brightness, eDP interface. Factory-fresh stock available. Request datasheet.

Model TM150TDSG81
Brand TIANMA
Size 15inch
Resolution 1024*768
Brightness 350 cd/m² (Typ.)
Perspective 80/80/80/80
Interface eDP
Operating Temp -10 ~ 70 °C
Production State In Production
Click For Price

1.TIANMA TM150TDSG81 Application Details

Basic Detail :Panel BrandTIANMAModel NameTM150TDSG81
Panel Typea-Si TFT-LCD , LCMAnother Name
Panel Size15”Designed ForIndustrial
Maximum Ratings :OP Temperature-10 ~ 65 °CST Temperature-20 ~ 65 °C
RoHSRoHSVibration Level
Features :Lamp Repaceable，WLED Backlight,With LED Driver, 6/8bit,Matte


2.TIANMA TM150TDSG81 Optical Details

Basic Information :Luminance350  cd/m²(Typ.)Contrast Ratio900:1 (Typ.) (Transmissive)
Good View at12 o'clockResponse Speed15 (Typ.)(Tr+Td) (ms)
Viewing Angle80/80/80/80 (Typ.)(CR≥10)Operating ModeTN, Normally White, Transmissive
Color Performance :ChromaticityWx:0.307; Wy:0.313Display Colors262K/16.7M (6-bit / 6-bit + Hi-FRC)
Color Temperature7006KWhite Variation1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt :NTSC Ratio61%sRGB80% coverage
Adobe RGB62% coverageDCI-P364% coverage
Rec.202046% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)


3.TIANMA TM150TDSG81 Mechanical Details

Pixel Features :Number of Pixel1024(RGB)*768 [XGA]ArrangementRGB Vertical Stripe
Dot Pitch0.099*0.297 mm (H*V)Pixel Pitch0.297*0.297 mm (H*V)  [85PPI]
Physical Size :Active Viewing304.128*228.096 mm (H*V)Bezel Area 307.4*231.3 mm (H*V)
Outline Dim.326.5*253.5 mm (H*V)Outline Depth10.0 (Max.) mm
Outline Features :Form StyleFlat RectangleOutline Shape
Aspect Ratio4:3 (H:V)OrientationLandscape type
Holes & Brackets :Side mounting holes (4-M3) on left, right bezel
Other Features :WeightTBDSurfaceAntiglare


4.TIANMA TM150TDSG81 Electronics Details

Frame Frequency :60Hz
Reverse Scan :No


5.TIANMA TM150TDSG81 Interface Details

Signal Systerm :eDP (1 Lane), eDP1.2Logic Voltage-
Signal Electrical :Voltage Input3.3V (Typ.)Current Input-
Interface Features :Position-Physical TypeConnector
Interface Detail :BrandModelPin PitchPinsAmountPin Assignment
I-PEX20455-030E-020.5mm30pins1 pcsEDP-30P1L-030A


6.TIANMA TM150TDSG81 Backlight Details

Lamp Features :Lamp TypeWLEDQuantity-PositionEdge light type
ExchangeReplaceableLamp Shape-Lamp Life30K(Min.) (Hours)
Interface Features :Position-Physical TypeIncluded in panel signal interface
Lamp DriverWith LED Driver
Driver Electrical :Voltage Input10.8/12.0/12.6V (Min./Typ./Max.)Current Input
-


7.TIANMA TM150TDSG81 Carton Details

Package Carton :AmountNet WeightCarton Size (L*W*H)
14 pcs / box-438*402*464 mm
