Original TIANMA TM150TDSG52 15" LCD Display Panel - 1024×768 TFT Display

1.TIANMA 15 " LCD Display TM150TDSG52 Application Details

Basic Detail :	Panel Brand	TIANMA	Model Name	TM150TDSG52
	Panel Type	a-Si TFT-LCD , LCM	Another Name
	Panel Size	15”	Designed For	Industrial
Maximum Ratings :	OP Temperature	0 ~ 65 °C	ST Temperature	-20 ~ 65 °C
	RoHS	RoHS	Vibration Level
Features :	WLED Backlight,With LED Driver,6/8bit,Matte


2.TIANMA 15 " LCD Display TM150TDSG52 Optical Details

Basic Information :	Luminance	250  cd/m²(Typ.)	Contrast Ratio	600:1 (Typ.) (Transmissive)
	Good View at	-	Response Speed	3/5 (Typ.)(Tr/Td) (ms)
	Viewing Angle	80/80/80/80 (Typ.)(CR≥10)	Operating Mode	TN, Normally White, Transmissive
Color Performance :	Chromaticity	Wx:0.313; Wy:0.329	Display Colors	262K/16.7M (6-bit / 6-bit + Hi-FRC)
	Color Temperature	6485K	White Variation	1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	63%	sRGB	80% coverage
	Adobe RGB	62% coverage	DCI-P3	65% coverage
	Rec.2020	47% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)


3.TIANMA 15 " LCD Display TM150TDSG52 Mechanical Details

Pixel Features :	Number of Pixel	1024(RGB)*768, XGA	Arrangement	RGB Vertical Stripe
	Dot Pitch	0.099*0.297 (mm) (H*V)	Pixel Pitch	0.297*0.297 (mm) (H*V)  [85PPI]
Physical Size :	Active Viewing(mm)	304.128(H) *228.096(V)	Bezel Area (mm)	307.4(H) *231.3(V)
	Outline Dim. (mm)	326.5(H) *253.5(V)	Outline Depth	11.8±0.3 mm
Outline Features :	Form Style	Flat Rectangle	Outline Shape	Normal bezel
	Aspect Ratio	4:3 (H:V)	Orientation	Landscape type
Holes & Brackets :	Side mounting holes (4-M3) on left, right bezel
Other Features :	Weight	1.00Kgs (Typ.)	Surface	Antiglare


4.TIANMA 15 " LCD Display TM150TDSG52 Electronics Details

Refresh Rate :	60Hz
Reverse Scan :	No
Power Consumption :	7.5W (Typ.)


5.TIANMA 15 " LCD Display TM150TDSG52 Interface Details

Signal Systerm :		LVDS (1 ch, 6/8-bit)				Logic Voltage		-
Signal Electrical :	Voltage Input			3.3V (Typ.)			Current Input	500/550mA (Typ./Max.)
Interface Features :	Position			-			Physical Type	Connector
Interface Detail :	Brand		Model		Pin Pitch		Pins	Amount	Pin Assignment
	P-TWO		185083-20121		1.25mm		20pins	1 pcs	LVDS-20P1C8B-010K


6.TIANMA 15 " LCD Display TM150TDSG52 Backlight Details

Lamp Features :

Lamp Type

WLED

Quantity

-

Position

Edge light type

Exchange

-

Lamp Shape

-

Lamp Life

30K(Min.) (Hours)

Interface Features :

Position

-

Physical Type

Connector

Interface Detail

Brand

Model

Pin Pitch

Pins

Amount

Pin Assignment

STM

MSB24038P5

1.25 mm

5pins

1 pcs

Backlight Driver :

With LED Driver

Driver Electrical :

Input Current

750/800mA (Typ./Max.)

Input Voltage

12.0V (Typ.)


7.TIANMA 15 " LCD Display TM150TDSG52 Carton Details

Package Carton :	Amount	Net Weight	Carton Size (L*W*H)
	14 pcs / box	14.6 Kgs	378*368*315.5 mm
