Innolux G156BGE-L01 15.6-inch 1366×768 300-nit LVDS LCD Panel

Innolux G156BGE-L01 15.6inch HD LCD
Innolux G156BGE-L01 15.6inch HD LCD
  • Innolux G156BGE-L01 15.6inch HD LCD
  • Innolux G156BGE-L01 15.6inch HD LCD

Innolux G156BGE-L01 15.6-inch 1366×768 300-nit LVDS LCD Panel

Innolux G156BGE-L01 is a 15 6-inch 1366 × 768 TFT LCD panel with 300 cd m² typical brightness and a 30-pin single-channel LVDS interface The supplied tentative specification lists a 0°C to +60°C operating range Contact IDT Display to confirm the applicable specification, availability and compatibility

Model G156BGE-L01
Brand Chimei Innolux
Size 15.6inch
Resolution 1366 × 768
Brightness 300 cd/m² (Typ.)
Perspective 80/80/80/80
Interface Single-channel LVDS, 30-pin
Operating Temp 0 to +60 °C
Production State Contact us for current lifecycle status and availability

Innolux G156BGE-L01 15.6-inch 1366 × 768 LVDS LCD Panel

The Innolux G156BGE-L01 is a 15.6-inch TFT LCD module with a native resolution of 1366 × 768 pixels, a WLED backlight and a 30-pin single-channel LVDS interface. The supplied specification lists 300 cd/m² typical white luminance and a 500:1 typical contrast ratio.

The reference document is a Tentative Specification, Version 2.2, dated 30 March 2018. Some electrical, optical and timing values are shown in parentheses. Confirm the applicable specification and panel revision before using these values for design approval or purchasing.

G156BGE-L01 Specifications

ParameterSpecification
ManufacturerInnolux
ModelG156BGE-L01
Reference DocumentTentative Specification V2.2, 30 March 2018
Screen Size15.6 inches diagonal
Native Resolution1366 × 768 pixels
Display Typea-Si TFT LCD, normally white
Display Colors262K / 16.7M as listed in the general specification; confirm the required configuration
Pixel Pitch0.252 × 0.252 mm
Active Area344.232 × 193.536 mm
White Luminance300 cd/m² typical; 240 cd/m² minimum
Contrast Ratio500:1 typical; 400:1 minimum
Viewing Angles160° total horizontal and 160° total vertical, typical at CR ≥ 10; values shown in parentheses in the source
Surface TreatmentAnti-glare, 3H hard coating
Signal InterfaceSingle-channel LVDS, 30-pin
LCD Logic Supply5.0 V typical; 4.5–5.5 V range, shown in parentheses in the source
Backlight Converter Supply12.0 V typical; 10.8–13.2 V range, shown in parentheses in the source
Backlight ConverterBuilt into the module
Outline Dimensions363.8 × 215.92 × 16.85 mm typical
Maximum Outline Dimensions364.3 × 216.42 × 17.35 mm
Weight1190 g typical; 1250 g maximum
Operating Ambient Temperature0°C to +60°C; upper limit shown in parentheses in the source
Required Panel Surface Temperature0°C to +60°C
Storage Temperature-20°C to +60°C
Lifecycle and AvailabilityContact IDT Display for current confirmation

These values describe the supplied tentative document and do not replace the applicable manufacturer-approved specification. Optical measurements are made under specified conditions, including an ambient temperature of 25 ± 2°C. Typical values should not be treated as guaranteed minimum performance.

LVDS Interface and Power Requirements

The G156BGE-L01 uses a 30-pin single-channel LVDS interface. Confirm the controller’s resolution support, LVDS data mapping, connector pin assignment and power sequence before connection.

The supplied electrical table lists a 5.0 V typical LCD logic supply with a 4.5–5.5 V range, and a separate 12.0 V typical backlight converter supply with a 10.8–13.2 V range. These values appear in parentheses in the tentative document and require confirmation against the applicable specification.

The 18 V backlight converter value in the absolute maximum ratings is not the normal operating voltage. Do not select the power supply using absolute maximum ratings.

The general specification lists a parenthesized total power figure of 10.95 W without clearly identifying it as a typical or maximum value. Confirm the power budget, maximum currents and startup requirements before finalizing the system power supply.

An HDMI source requires a suitable HDMI-to-LVDS controller configured for this panel, together with compatible cables, power supplies and backlight controls. The panel does not accept HDMI or eDP directly.

Mechanical Fit and Replacement Selection

The listed typical outline dimensions are 363.8 × 215.92 × 16.85 mm. The maximum thickness is 17.35 mm. Check the outline drawing, connector locations, mounting arrangement and enclosure clearance before approving a replacement.

Do not assume that the G156BGE-L01 and G156BGE-L03 are interchangeable because both are 15.6-inch 1366 × 768 LVDS panels. Compare the applicable revisions, mechanical dimensions, cable wiring, electrical requirements and optical performance.

  • Confirm the complete original panel model and revision.
  • Check single-channel LVDS data mapping and timing.
  • Verify connector pin assignment and cable orientation.
  • Compare active area, mounting points and maximum outline dimensions.
  • Check logic power, backlight power, dimming controls and sequencing.
  • Validate the replacement in the intended equipment before production approval.

Operating Environment and Readability

The supplied document lists an operating ambient range of 0°C to +60°C, with the upper value in parentheses. It also requires the panel surface temperature to remain between 0°C and +60°C. Follow the manufacturer’s humidity conditions and prevent condensation.

Evaluate enclosure temperature, ventilation and heat from adjacent components. This document does not support a sub-zero operating claim.

The specified brightness is 300 cd/m² typical. Evaluate readability under the actual installation lighting and viewing positions. An anti-glare surface does not independently establish direct-sunlight readability or outdoor weather resistance.

Frequently Asked Questions

Is the G156BGE-L01 a Full HD panel?

No. Its native resolution is 1366 × 768 pixels, rather than 1920 × 1080.

What is its typical brightness?

The optical specification lists 300 cd/m² typical white luminance and 240 cd/m² minimum under the specified measurement conditions.

Does it use LVDS or eDP?

It uses a 30-pin single-channel LVDS interface. An eDP output is not directly compatible.

Can it replace the G156BGE-L03 directly?

Do not assume direct compatibility. Compare mechanical thickness, mounting, connector wiring, power requirements and optical performance, then validate the panel in the equipment.

Can it operate below 0°C?

The supplied document does not specify sub-zero operation. It lists a minimum operating ambient temperature and minimum panel surface temperature of 0°C.

Is this model currently in production or in stock?

The historical tentative specification does not confirm current production status or inventory. Provide the complete model number, revision, quantity and required delivery date for confirmation.

Related LCD Selection Guides

Request a Datasheet and Quotation

Send the complete model number G156BGE-L01, required revision, quantity, application and delivery schedule. For replacement evaluation, include the original panel label, controller information, cable details and mechanical requirements.

Request the G156BGE-L01 datasheet and quotation

Specification Reference

This description is based on the Innolux G156BGE-L01 Tentative Product Specification, Version 2.2, dated 30 March 2018 in the document header. Some values are shown in parentheses, and the electrical table contains entries requiring clarification. Obtain the applicable manufacturer-approved specification before final design approval.

Current lifecycle status, availability, accessories and delivery terms require confirmation for the specific order.

G156BGE-L01 Application and Integration

The Innolux G156BGE-L01 can be evaluated for equipment interfaces, information terminals and monitor assemblies requiring a 15.6-inch 1366 × 768 display with single-channel LVDS. Final suitability depends on the applicable specification and complete system design.

Equipment Interfaces and Information Displays

Confirm that the host controller supports the native resolution, LVDS configuration and data mapping. Evaluate the 300 cd/m² typical brightness and viewing characteristics under the intended installation lighting.

Mechanical Integration

Allow for the listed typical thickness of 16.85 mm and maximum thickness of 17.35 mm. Check the outline drawing, mounting arrangement, connector position and cable clearance before approving the enclosure design.

Power and Thermal Design

Confirm the logic and backlight supply requirements against the applicable specification. Validate startup current, dimming controls and power sequencing. Maintain both the ambient and panel surface temperatures within the confirmed operating limits and prevent condensation.

Replacement Projects

Compare the original panel’s complete model number, revision, pin assignment, dimensions, power rails and timing. Matching screen size and resolution alone do not establish compatibility.

Information Required for Evaluation

  • Original panel label and applicable specification.
  • Controller model, display output and cable wiring.
  • Mechanical drawings and mounting requirements.
  • Installation lighting and temperature conditions.
  • Required quantity and delivery schedule.

Contact IDT Display to confirm the applicable specification, current availability and compatibility before ordering.
