AUO G104STN01.0 10.4" 800x480 SVGA LCD | Agricultural Monitoring Display Panel

G104STN01.0
G104STN01.0
G104STN01.0
  • G104STN01.0
  • G104STN01.0
  • G104STN01.0

AUO G104STN01.0 10.4" 800x480 SVGA LCD | Agricultural Monitoring Display Panel

Original AUO G104STN01 0 10 4-inch TFT LCD Panel (800×480 SVGA LVDS) for agricultural monitoring systems sunlight-readable 400nits brightness Ideal for handheld harvest scanners, livestock trackers, and greenhouse controllers Request samples

Model G104STN01.0
Brand AUO
Size 10.4inch
Resolution 800*480
Brightness 400cd/m2
Perspective 80/80/60/70 (Typ.)
Interface LVDS
Operating Temp  -30 ~ 80 °C
Production State In Production
Click For Price

1.AUO  G104STN01.0 Application Details

Basic Detail :ManufacturerAUOModel Name  G104STN01.0
Panel Typea-Si TFT-LCD , LCMModel Alias
Panel Size10.4inchDesigned ForIdustrial
Maximum Ratings :OP Temperature-30 ~ 80 °C ST Temperature-30 ~ 80 °C
RoHSRoHSVibration Level1.5G (14.7 m/s²)
Features :Wide Temperature，WLED Backlight，Life>=70K hours,With LED Driver,180°Reverse，6/8 bit，Matte


2.AUO   G104STN01.0  Optical Details

Basic Information :Luminance400 cd/m² (Typ.)Contrast Ratio700:1 (Typ.) (Transmissive)
Good View at-Response Speed10/5 (Typ.)(Tr/Td)
Viewing Angle80/80/60/70 (Typ.)(CR≥10)Operating ModeTN, Normally White, Transmissive
Color Performance :ChromaticityWx:0.310; Wy:0.330Support Color262K/16.2M (6-bit / 6-bit + FRC)
Color Temperature6638KWhite Variation1.33 (Max.)(5 points)
1931 Color Gamlt :NTSC Ratio54%sRGB74% coverage
Adobe RGB56% coverageDCI-P356% coverage
Rec.202040% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)


3.AUO   G104STN01.0 Mechanical Details

Pixel Features :Number of Pixel800(RGB)*600, SVGAArrangementRGB Vertical Stripe
Dot Pitch(W*H)0.088*0.264 (H*V)Pixel Pitch(W*H)0.264*0.264 (H*V)  [96PPI]
Physical Size :Active Viewing(mm)211.2(H) *158.4(V)Outline Dim.(mm)243(H) × 184(V)
Bezel Area(mm)214.8(H) *162.7(V)Depth(mm)6.5±0.5
Outline Features :Form StyleFlat RectangleShape Style
Aspect Ratio4:3(H:V)OrientationLandscape type
Mounting :Face mounting holes (2-Φ3.5, 2-R1.75) on left, right bezel
Other Spec :Weight365g (Typ.)TreatmentAntiglare, Hard coating (3H)


4.AUO   G104STN01.0  Electronics Details

Refresh Rate :60Hz
Reverse Scan :Yes (180°)
Total Consumption :4.38W (Typ.)


5.AUO   G104STN01.0 Interface Detail

Signal Electrical :Voltage Supply3.3V (Typ.)Current Supply320mA (Typ.)
Consumption1.5W (Max.)Signal InterfaceLVDS (1 ch, 6/8-bit)
Interface Features :Position-TypeConnector
Interface Detail :BrandModelPitchPinsQuantityPin Configuration
STMMSB24013P20HA1.0 mm20 pins1 pcsLVDS-20P1C8B-080A


6.AUO   G104STN01.0  Backlight Details

Lamp Features :Lamp TypeWLEDQuantity7S2PPositionEdge light type (Bottom side)
Exchange-Lamp Shape2 stringsLamp Life70K(Min.) (Hours)
Interface Features :Position-Physical TypeConnector
Interface Detail :BrandModelPitchPinsQuantityPin Configuration
E&T3808K-F05N-02R1.25 mm5 pins1 pcs
Backlight Driver :With LED Driver
Driver Electrical :Voltage Supply12.0V (Typ.)Current Supply0.32A (Typ.)
Consumption2.88W (Typ.)


7.AUO G104STN01.0 Packing Details

Package Box :QuantityWeightBox Size
20 pcs / box11.5 Kgs477*290*360 mm (L*W*H)
