DS-T0565BGEA-01 compatible alternative to AT056TN52 V.3
DS-T0565BGEA-01 is specifically designed to be compatible with and replace the Mass Creation 5 6-inch AT056TN52 V 3 LCD screen DS-T0565BGEA-01 is highly consistent with AT056TN52 V 3 in terms of core parameters, including:
DS-T0565BGEA-01 is specifically designed to be compatible with and replace the Mass Creation 5.6-inch AT056TN52 V.3 LCD screen.
DS-T0565BGEA-01 is an assembled screen developed by Hangzhou Xuhong Technology, specifically designed to be compatible with and replace the Mass Creation 5.6-inch AT056TN52 V.3 LCD screen. The latter received a discontinuation notice in September 2022, and currently there are no replacement models of the same size available. The following will explain from three aspects: compatibility, performance comparison, and substitution advantages:
I. Compatibility analysis
1. Parameters are perfectly matched
DS-T0565BGEA-01 is highly consistent with AT056TN52 V.3 in terms of core parameters, including:
-Resolution: 640 × 480 (VGA), aspect ratio 4:3;
-Interface: 50 pins Parallel RGB (1 ch, 8-bit), FPC connection method;
-Physical dimensions: Appearance dimensions are 126.5 × 100.0 mm, thickness is 5.7 mm, display area is 115.2 × 86.4 mm (with an error of 112.896 × 84.672 mm from AT056TN52 V.3 within the industrial allowable range);
-Working environment: working temperature -20~70 ° C, storage temperature -30~80 ° C.
2. Signal and timing compatibility
The timing configuration of AT056TN52 V.3 (such as DE/HV mode) has been verified by the kernel driver, and DS-T0565BGEA-01 adopts the same interface design, which can directly adapt to the original driver circuit without hardware modification.
II. Performance upgrade highlights
DS-T0565BGEA-01 has been optimized for the original model while maintaining compatibility
1. Display performance improvement
-Brightness: 450nits (prototype size 200cd/m ²), suitable for high ambient light scenes;
-Contrast ratio: 1200:1 (prototype 500:1), enhancing the sense of layering in the image;
-Viewing angle: IPS hard screen technology achieves an 80 ° full viewing angle (prototype number TN screen, optimal viewing angle is only in the 6 o'clock direction).
2. Backlight design improvement
-Adopting TTL backlight, supporting more flexible brightness adjustment (prototype number is WLED side entry light source without backlight driver);
-The lifespan of the backlight is not clear, but power consumption can be reduced by optimizing circuit design (panel power 117mW vs. prototype 930mW).
III. Advantages of alternative solutions
1. Supply chain stability
Since the announcement of the discontinuation of AT056TN52 V.3 in 2022, there are basically no new original A-grade LCD screens available. DS-T0565BGEA-01, as a domestically produced assembly screen in China, can provide stable stock and support mass customization.
2. Application scenario adaptation
Suitable for typical scenarios of original models such as industrial control, digital photo frames, and video doorbells, and can be extended to outdoor equipment display requirements due to increased brightness.
3. Technical support guarantee
Hangzhou Xuhong provides supporting driver debugging support and can customize peripheral accessories such as touch screens and inverters to solve the problem of secondary development after the original model is discontinued.
IV. Alternative Implementation Suggestions
1. Hardware replacement steps
-Directly replace the screen module, retaining the original interface and fixed structure;
-If the original system relies on the backlight control of AT056TN52 V.3 (such as PWM dimming), the driver circuit needs to be adjusted according to the TTL backlight characteristics of DS-T0565BGEA-01.
2. Stock up and cost control*
-Suggest stocking up in advance to avoid potential supply interruption risks of AT056TN52 V.3;
-The cost of assembling the screen is more competitive than the original model (DS-T0565BGEA-01 requires specific inquiry).
Summary: DS-T0565BGEA-01 has become an ideal alternative to AT056TN52 V.3 after its discontinuation due to parameter compatibility, performance upgrades, and supply chain advantages, especially suitable for upgrading industrial grade display equipment. Suggest contacting Hangzhou Xuhong Technology for detailed specifications and sample testing support.
