P1400FHF1MA00

Diagonal Size

14.0"

Application

Industrial，Outdoor High Brightness

Panel Type

a-Si TFT-LCD , LCM

Model Alias

-

Reliability :

Operating Temp.

-20 ~~70 °C

Storage Temp.

-30 ~~ 80 °C

RoHS State

RoHS

Vibration Rating

-

Specific Features :

Hight Brightness,WLED Backlight,With LED Driver，Matte

Configuration

RGB Vertical Stripe

Pixel Pitch

0.1611×0.1611 mm (H×V)  [157PPI]

Mechanical Size :

Active Viewing

309.312×173.988 mm (H×V)

Bezel Area

-

Outline Dim.

315.31×184.49 mm (H×V)

Outline Depth

3.11/8.5 (Typ./Max.) mm

Outline Features :

Form Factor

Flat Rectangle

Orientation

Landscape type

Aspect Ratio

16:9 (H:V)

Shape Style

Holes & Brackets :

Without

Other Features :

Weight

TBD

Surface

Antiglare

Viewing Angle

88/88/88/88 (Typ.)(CR≥10)

Optical Mode

SFT, Normally Black, Transmissive

Viewing Direction

Symmetry

Response Time

35 (Typ.)(Tr+Td) ms

Color Performance :

Chromaticity

Wx:0.296; Wy:0.318

Color Numbers

16.7M (8-bit)

Color Temperature

7650K

White Variation

1.18/1.33 (Typ./Max.)(9 points)

1931 Color Gamut :

NTSC Ratio

73%

sRGB

92% coverage

Adobe RGB

71% coverage

DCI-P3

75% coverage

Rec.2020

54% coverage

Remarks

sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

Dispaly Performance :

Outdoor Visibility

Sunlight Readable

Transmittance

-

Reverse Scan :

No

Replacement

-

Lamp Shape

6 strings × 2CN

Position

Edge light type

Interface Features :

Position

-

Type

Connector

Interface Detail :

Brand

Model

Pin Pitch

Pins

Amount

Configuration

HRS

KW30-8S-1H(800)

1.0 mm

8pins

1pcs

Backlight Driver :

With LED Driver

Driver Electrical :

Input Current

-

Input Voltage

12.0±1.2V

Consumption

750mW (Typ.)

Signal Interface

LVDS (2 ch, 8-bit)

Interface Features :

Position

-

Type

Connector

Interface Detail :

Brand

Model

Pitch

Pins

Amount

Pin Assignment

STM

MSBKT2407P30HB

1.0mm

30 pins

1 pcs
