Chimei Innolux G154I1-L01 15.4" Industrial LCD Display Module

Premium Chimei Innolux G154I1-L01 15 4-inch 1280*800 LCD module with INNOLUX technology 700 cd m² (Typ ) Hight Brightness Sunlight Readable display solution for industrial equipment and commercial applications

Model	G154I1-L01
Brand	Chimei Innolux
Size	15.4inch
Resolution	1280*800
Brightness	700 cd/m² (Typ.)
Perspective	80/80/80/80
Interface	LVDS
Operating Temp	-30 ~ 80 °C
Production State	Discontinued

Click For Price

1.Chimei Innolux G154I1-L01 Application Details

Basic Detail :	Panel Brand	INNOLUX/CHI MEI	Model Name	G154I1-L01
	Panel Type	a-Si TFT-LCD , LCM	Another Name
	Panel Size	15.4”	Designed For	Industrial
Maximum Ratings :	OP Temperature	-30 ~ 80 °C	ST Temperature	-40 ~ 85 °C
Maximum Ratings :	RoHS	RoHS	Vibration Level	1.5G (14.7 m/s²)
Features :	Wide Temperature，Hight Brightness，Lamp Repaceable，Life>=50K hours,180°Reverse，Glossy

2.Chimei Innolux G154I1-L01 Optical Details

Basic Information :	Luminance	700 cd/m²(Typ.)	Contrast Ratio	700:1 (Typ.) (Transmissive)
	Good View at	-	Response Speed	5/11 (Typ.)(Tr/Td)
	Viewing Angle	80/80/80/80 (Typ.)(CR≥10)	Operating Mode	TN, Normally White, Transmissive
Color Performance :	Chromaticity	Wx:0.313; Wy:0.329	Display Colors	262K (6-bit)
Color Performance :	Color Temperature	6485K	White Variation	1.25/1.40 (Typ./Max.)(5 points)
1931 Color Gamlt :	NTSC Ratio	61%	sRGB	84% coverage
	Adobe RGB	64% coverage	DCI-P3	63% coverage
	Rec.2020	46% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :	Outdoor Visibility	Sunlight Readable	Transmissivity	-

3.Chimei Innolux G154I1-L01 Mechanical Details

Pixel Features :	Number of Pixel	1280(RGB)*800, WXGA	Arrangement	RGB Vertical Stripe
Pixel Features :	Dot Pitch (W*H)	0.08625*0.25875 mm	Pixel Pitch (W*H)	0.25875*0.25875 mm [98PPI]
Physical Size :	Active Viewing(mm)	331.2207 mm (HV)	Bezel Area (mm)	334.5(H) *210.3(V)
Physical Size :	Outline Dim.(mm)	352230 mm (HV)	Depth(mm)	15.8±0.5
Outline Features :	Form Style	Flat Rectangle	Outline Shape
Outline Features :	Aspect Ratio	16:10 (H:V)	Orientation	Landscape type
Fixation :	Side mounting holes (4-M3) on left, right bezel
Other Spec :	Weight	1.29/1.35Kgs (Typ./Max.)	Surface	Glare (Haze 0%), Hard coating (3H), Antireflection

4.Chimei Innolux G154I1-L01 Electronics Details

Refresh Rate :	60Hz
Reverse Scan :	Yes (180°)

5.Chimei Innolux G154I1-L01 Interface Details

Signal Systerm :		LVDS (1 ch, 6-bit)				Logic Voltage				-
Signal Electrical :	Voltage Input			3.3V (Typ.)			Current Input		410mA (Typ.)
Interface Features :	Position			-			Physical Type		Connector
Interface Detail :	Brand		Model		Pin Pitch			Pins	Amount		Pin Assignment
	JAE		FI-SE20P-HFE		1.25mm			20pins	1 pcs		LVDS-20P1C6B-010C

6.Chimei Innolux G154I1-L01 Backlight Details

Lamp Features :	Lamp Type		CCFL		Quantity		9S4P		Position	Edge light type (Top and Bottom)
	Exchange		Replaceable		Lamp Shape		strings		Lamp Life	50K(Min.) (Hours)
Lamp Electrical :	Voltage Supply		600±60V		Current Supply		3.0/7.0/8.0mA (Min./Typ./Max.)
	Frequency		40/55/80KHz (Min./Typ./Max.)		Startup Voltage		-
	Consumption		16.8W (Typ.)
Interface Features :	Position		-		Physical Type		Connector
Backlight Driver :	With LED Driver
Interface Detail :	Brand	Model		Pitch		Pins		Quantity			Pin Configuration
	YEONHO	35001HS-02L		3.5 mm		2 pins		4 pcs			BLL-2PINS-HL
Backlight Driver :	No

7.Chimei Innolux G154I1-L01 Carton Details

Package Box :	Amount	Weight	Size (LWH)
Package Box :	10pcs / box	14.7 Kgs	465362314 mm
