MV238FHM-N10 23.8" FHD LCD Display | BOE Original | 250nits 1920×1080

MV238FHM-N10 23.8inch FHD LCD Display
MV238FHM-N10 23.8inch FHD LCD Display
  • MV238FHM-N10 23.8inch FHD LCD Display
  • MV238FHM-N10 23.8inch FHD LCD Display

MV238FHM-N10 23.8" FHD LCD Display | BOE Original | 250nits 1920×1080

Original BOE MV238FHM-N10 23 8 " FHD LCD panel (1920×1080, 250nits) Industrial-grade with 1000:1 contrast ratio Ideal for POS systems, industrial controls and kiosks 3-year warranty, wholesale pricing available

Model MV238FHM-N10
Brand BOE
Size 23.8inch
Resolution 1920*1080
Brightness 250cd/m²
Perspective 89/89/89/89
Interface LVDS
Operating Temp 0 ~ 50 °C
Production State In Production
Click For Price
1.BOE 23.8" LCD Display MV238FHM-N10  Application Details
Basic Detail :Panel BrandBOEModel NameMV238FHM-N10
Panel Typea-Si TFT-LCD , LCMAnother Name
Panel Size23.8”Designed ForDesktop Monitor
Maximum Ratings :OP Temperature0 ~ 50 °CST Temperature-20 ~ 60 °C
RoHSRoHSVibration Level
Features :Srgb,WLED Backlight,Reverse I/F,Matte

2.BOE 23.8" LCD Display MV238FHM-N10  Optical Details
Basic Information :Luminance250  cd/m² (Min.)Contrast Ratio1000:1 (Typ.) (Transmissive)
Good View atSymmetryResponse Speed14 (Typ.)(Tr+Td)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)Operating ModeADS, Normally Black, Transmissive
Color Performance :ChromaticityWx:0.313; Wy:0.329Display Colors16.7M (6-bit + Hi-FRC)
Color Temperature6485KWhite Variation1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt :NTSC Ratio74%sRGB98% coverage
Adobe RGB77% coverageDCI-P377% coverage
Rec.202055% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

3.BOE 23.8" LCD Display MV238FHM-N10  Mechanical Details
Pixel Features :Number of Pixel1920(RGB)*1080, FHDArrangementRGB Vertical Stripe
Dot Pitch (mm)0.0915*0.2745 mmPixel Pitch (mm)0.2745*0.2745 mm  [92PPI]
Physical Size :Active Viewing(mm)527.04(W)*296.46(H) mmBezel Area (mm)530.2(W)*299.6(H) mm
Outline Dim. (mm)543(W)*317.4(H) mmOutline Depth8.2/11.4(Typ./Max.)
Outline Features :Form StyleFlat RectangleOutline ShapeNormal bezel
Aspect Ratio16:9 (H:V)OrientationLandscape type
Holes & Brackets :Side mounting holes (4-M3) on left, right bezel
Other Features :Weight2.39Kgs (Typ.)SurfaceAntiglare (Haze 25%), Hard coating (3H)

4.BOE 23.8" LCD Display MV238FHM-N10  Electronics Details
Frame Frequency :60Hz
Reverse Scan :No
Total Consumption :13.6/19.4W (Typ./Max.)

5.BOE 23.8" LCD Display MV238FHM-N10  Interface Details
Signal Systerm :LVDS (2 ch, 8-bit)
Signal Electrical :Voltage Input5.0V (Typ.)Current Input0.62/1.5A (Typ./Max.)
Consumption3.1/7.5W (Typ./Max.)
Interface Features :PositionRearPhysical TypeConnector
Interface Detail :BrandModelPin PitchPinsAmountPin Assignment
UJUIS100-L30O-C231.0mm30pins1 pcsLVDS-30P2C8B-160A

6.BOE 23.8" LCD Display MV238FHM-N10  Backlight Details
Lamp Features :Lamp TypeWLEDQuantity17S4PPositionEdge light type (Bottom side)
Exchange
-		Lamp Shape3stringsLamp Life30K(Min.) (Hours)
Lamp Electrical :Voltage Supply47.6/50.2/52.7V (Min./Typ./Max.)Current Supply70/75mA (Typ./Max.)
Consumption10.5/11.9W (Typ./Max.)
Interface Features :PositionRearPhysical TypeConnector
Interface Detail :BrandModelPitchPinsQuantityPin Configuration
E&T3708K-Q06N-00R1.0mm6pins1 pcsBLE-6PINS-CCAACC
Backlight Driver :No

7.BOE 23.8" LCD Display MV238FHM-N10  Carton Details
Package Carton :AmountNet WeightCarton Size (L*W*H)
8pcs / box-235*615*448 mm
