Industrial-grade 8 4 " 800×600 TFT LCD module (TCG084SVLQAPNN-AN20) with LVDS interface, 400nits brightness, WLED backlight, and wide operating temperature (-20°C to 70°C)
| Model | TCG084SVLQAPNN-AN20 |
| Brand | Kyocera |
| Size | 8.4inch |
| Resolution | 800×600 |
| Brightness | 400 cd/m² (Typ.) |
| Perspective | 85/85/85/85 (Typ.) |
| Interface | LVDS |
| Operating Temp | -20 ~ 70 °C |
| Production State | In Production |
Hangzhou IDT DISPLAY TECHNOLOGY CO.,LTD is the main agent of Youda AUO LCD screen, CHIMEI LCD screen, Mitsubishi LCD screen, INNOLUX LCD screen, Tianma LCD screen, touch LCD screen and other small ...
Read More
1.Kyocera TCG084SVLQAPNN-AN20 Application Details
Basic Information :
Brand
Kyocera
Model
TCG084SVLQAPNN-AN20
Type
LCM a-Si TFT-LCD
Used For
Industrial
Screen Size
8.4"
Environment :
Storage Temp.
-30 ~ 80 °C
Operating Temp.
-20 ~~ 70 °C
RoHS
RoHS
Vibration Rating
-
Typical Features :
WLED Backlight，Life≥70K hours，With LED Driver，6/8bit，Matte
2.Kyocera TCG084SVLQAPNN-AN20 Mechanical Details
Pixel Features :
Resolution
800(RGB)×600 [SVGA]
Dot Pitch
0.071×0.213 mm (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch
0.213×0.213 mm (H×V) [119PPI]
Mechanical Size :
Active Area
170.4×127.8 mm (H×V)
Bezel Area
174.4×131.8 mm (H×V)
Outline Dim.
199.5×147.4 mm (H×V)
Outline Depth (mm)
9.0 (Typ.)
Outline Features :
Form Style
Flat Rectangle
Outline Shape
Aspect Ratio (W:H)
4:3 (H:V)
Orientation
Landscape type
Holes & Brackets :
Face mounting holes
Other Detail :
Mass
315g (Typ.)
Surface
Antiglare
3.Kyocera TCG084SVLQAPNN-AN20 Optical Details
Basic Information :
Luminance(cd/m²)
400 (Typ.)
Contrast Ratio
500:1 (Typ.) (Transmissive)
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Display Mode
AWV, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
18/12 (Typ.)(Tr/Td)
Color Performance :
White Coordinate
X:0.310; Y:0.325
Display Colors
262K/16.7M (6-bit / 8-bit)
Color Temperature
6685K
White Uniformity
-
1931 Color Gamut :
NTSC Ratio
50%
sRGB
70% coverage
Adobe RGB
53% coverage
DCI-P3
52% coverage
Rec.2020
38% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
4.Kyocera TCG084SVLQAPNN-AN20 Electronics Details
Frame Frequency :
60Hz
Reverse Scan :
No
5.Kyocera TCG084SVLQAPNN-AN20 Interface Details
Signal Electrical :
Voltage Supply
3.3V (Typ.)
Current Supply
270/330mA (Typ./Max.)
Signal Type :
LVDS (1 ch, 6/8-bit)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
JAE
FI-X30SSLA-HF
1.0mm
30pins
1 pcs
6.Kyocera TCG084SVLQAPNN-AN20 Backlight Details
Backlight Features:
Shape
-
Type
WLED
Position
Edge light type
Replacement
-
Quantity
-
Life Time
70K(Typ.) (Hours)
Interface Features :
Position
-
Type
Backlight Driver :
With LED Driver
Driver Electrical :
Voltage Input
