Original Kyocera TCG121WXLPAPNN-AN20 12.1" IPS LCD with 1280×800 resolution, 500nits brightness & LVDS interface. WLED backlight (50,000hrs) for industrial HMI, medical and kiosk applications.
| Model | TCG121WXLPAPNN-AN20 |
| Brand | Kyocera |
| Size | 12.1inch |
| Resolution | 1280×800 |
| Brightness | 500 cd/m² (Typ.) |
| Perspective | 85/85/85/85 (Typ.) |
| Interface | LVDS |
| Operating Temp | -20 ~ 70 °C |
| Production State | In Production |
Hangzhou IDT DISPLAY TECHNOLOGY CO.,LTD is the main agent of Youda AUO LCD screen, CHIMEI LCD screen, Mitsubishi LCD screen, INNOLUX LCD screen, Tianma LCD screen, touch LCD screen and other small ...
Read More
1.Kyocera TCG121WXLPAPNN-AN20 Application Details
Basic Information :
Brand
Kyocera
Model
TCG121WXLPAPNN-AN20
Type
LCM a-Si TFT-LCD
Used For
Industrial
Screen Size
12.1"
Environment :
Storage Temp.
-30 ~ 80 °C
Operating Temp.
-20 ~ 70 °C
RoHS
RoHS
Vibration Rating
-
Typical Features :
WLED Backlight，Life≥50K hours，With LED Driver，180°Reverse，Matte
2.Kyocera TCG121WXLPAPNN-AN20 Mechanical Details
Pixel Features :
Resolution
1280(RGB)×800 [WXGA]
Dot Pitch
(mm)
0.068×0.204
Pixel Format
RGB Vertical Stripe
Pixel Pitch
(mm)
0.204×0.204 [124PPI]
Mechanical Size :
Active Area (mm)
261.12(H) × 163.2(V)
Bezel Area (mm)
264.1(H) × 166.2(V)
Outline Dimension (mm)
277.7(H) × 182.5(V)
Outline Depth
9.8 (Typ.) mm
Outline Features :
Form Style
Flat Rectangle
Outline Shape
Aspect Ratio (W:H)
16:10 (H:V)
Orientation
Landscape type
Holes & Brackets :
Side mounting holes (4-M2) on left, right bezel
Other Detail :
Mass
680g (Typ.)
Surface
Antiglare
3.Kyocera TCG121WXLPAPNN-AN20 Optical Details
Basic Information :
Luminance(cd/m²)
500 cd/m² (Typ.)
Contrast Ratio
750:1 (Typ.) (Transmissive)
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Display Mode
AWV, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
18/12 (Typ.)(Tr/Td)
Color Performance :
White Coordinate
X:0.300; Y:0.335
Display Colors
16.2M (6-bit + FRC)
Color Temperature
7136K
White Uniformity
-
1931 Color Gamut :
NTSC Ratio
50%
sRGB
70% coverage
Adobe RGB
53% coverage
DCI-P3
52% coverage
Rec.2020
38% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
4.Kyocera TCG121WXLPAPNN-AN20 Electronics Details
Frame Frequency :
60Hz
Reverse Scan :
Yes (180°)
5.Kyocera TCG121WXLPAPNN-AN20 Interface Details
Signal Electrical :
Voltage Supply
3.3V (Typ.)
Current Supply
375/490mA (Typ./Max.)
Signal Type :
LVDS (1 ch, 8-bit)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
HRS
DF19L-20P-1H
1.0mm
20pins
1 pcs
6.Kyocera TCG121WXLPAPNN-AN20 Backlight Details
Backlight Features:
Shape
-
Type
WLED
Position
Edge light type
Replacement
-
Quantity
-
Life Time
50K(Typ.) (Hours)
Interface Features :
Position
-
Backlight Driver
With LED Driver
Type
Connector
Interface Detail
Brand
Model
Amount
Pin Pitch
Pins
Pin Assignment
JST
SM08B-SHLS-G-TF(LF)(SN)
1 pcs
1.0 mm
8 pins
Driver Electrical :
Input Current
460/600mA (Typ./Max.)
Input Voltage
12.0V (Typ.)
7.Kyocera TCG121WXLPAPNN-AN20 Packing Features
Package Type
Pcs/Package
Package LWH (mm)
G.W (kgs)
14
540×360×320
N/A
