Premium 13 3-inch capacitive touch screen display WGJ13351C-GDB-A3 Features multi-touch support, high brightness, wide viewing angles, and industrial-grade durability for various applications
| Part No. | WGJ13351C-GDB-A3 |
| Brand | IDT |
| Thickness Overall | 13.3inch |
| Thickness Overall | 1.85mm |
| Tail Design | G+G |
| Outside Area | 309.2*182.89mm |
| Active Area | 294.30*165.80mm |
Hangzhou IDT DISPLAY TECHNOLOGY CO.,LTD is the main agent of Youda AUO LCD screen, CHIMEI LCD screen, Mitsubishi LCD screen, INNOLUX LCD screen, Tianma LCD screen, touch LCD screen and other small ...
Read More
Model
WGJ13351C-GDB-A3
Size
13.3inch
Brand
IDT
COVER LENS
Reinforced glass
FPC interface
USB and IIC interfaces
IC
IL12511
Touch channel
RX38*TX22
Touch method
10 point touch control
I0 voltage
3.3V
Working voltage
5.0V
Interruption method
Pull down pulse
interface PIN
0.3 * 102
Surface hardness
OVER 6H
Light transmittance
Over 85%
Working temperature
-10℃~+60℃
Storage temperature
-20℃-+70℃
Active Viewing
294.30*165.80mm
Outside Area
309.2*182.89mm
Thickness
1.85mm
The product complies with RoHS standards
