BOE 43 " FHD 400-nit LVDS LCD module DV430FHM-NN1 in stock—perfect for kiosks, gaming & signage Same-day quotes, global shipping, factory pricing
| Model | DV430FHM-NN1 |
| Brand | BOE |
| Size | 43.0inch |
| Resolution | 1920*1080 |
| Brightness | 400cd/m2 |
| Perspective | 89/89/89/89 (Typ.) |
| Interface | LVDS |
| Operating Temp | 0 ~ 50 °C |
| Production State | In Production |
The BOE DV430FHM-NN1 is a 43-inch Full-HD IPS TFT LCD engineered for cost-effective, high-volume projects that demand reliable 24/7 performance. With 1920×1080 resolution, 400 cd/m² brightness, and a 60 Hz LVDS interface, this panel delivers crisp images and wide 178° viewing angles for indoor digital signage, gaming machines, and industrial HMIs. Its slim 11.7 mm profile and standardized mounting holes allow drop-in integration, while the 30 000-hour LED backlight ensures low maintenance and long service life.
Hangzhou IDT DISPLAY TECHNOLOGY CO.,LTD is the main agent of Youda AUO LCD screen, CHIMEI LCD screen, Mitsubishi LCD screen, INNOLUX LCD screen, Tianma LCD screen, touch LCD screen and other small ...
Read More
1.BOE DV430FHM-NN1 Application Details
Basic Detail :
Manufacturer
BOE
Model Name
DV430FHM-NN1
Panel Type
a-Si TFT-LCD , LCM
Panel Size
43.0"
Designed For
Digital Signage，
Maximum Ratings :
OP Temperature
0 ~ 50 °C
ST Temperature
-20 ~ 60 °C
RoHS
RoHS
Vibration Level
Features :
WLED Backlight，With LED Driver，Reverse I/F, Matte
2.BOE DV430FHM-NN1 Mechanical Details
Pixel Features :
Number of Pixel
1920(RGB)×1080, FHD
Arrangement
RGB Vertical Stripe
Dot Pitch
0.16335×0.49005 (H×V)
Pixel Pitch
0.49005×0.49005 (H×V) [51PPI]
Physical Size :
Active Viewing
940.896(H) × 529.254(V)
Bezel Area(mm).
943.896(H) × 532.25(V)
Outline Dim.(mm)
961.7(H) × 550.1(V)
Depth(mm)
11.7/27.7 (Typ./Max.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
16:9 (H:V)
Shape Style
Other Detail :
Mass
8.36Kgs (Typ.)
Surface
Antiglare (Haze 1%), Hard coating (3H)
3.BOE DV430FHM-NN1 Optical Details
Basic Information :
Luminance
400 cd/m² (Typ.)
Contrast Ratio
1200:1 (Typ.) (Transmissive)
Good View at
Symmetry
Response Speed
8 (Typ.)(G to G) ms
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
ADS, Normally Black, Transmissive
Color Performance :
Chromaticity
Wx:0.280; Wy:0.290
Support Color
16.7M (8-bit)
Color Temperature
9969K
White Variation
1.33/1.43 (Typ./Max.)(9 points)
1931 Color Gamut :
NTSC Ratio
71%
sRGB
97% coverage
Adobe RGB
74% coverage
DCI-P3
74% coverage
Rec.2020
53% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
4.BOE DV430FHM-NN1 Electronics Details
Refresh Rate :
60Hz
Reverse Scan :
No
5.BOE DV430FHM-NN1 Interface Details
Signal Electrical :
Input Current
0.5/0.95A (Typ./Max.)
Input Voltage
12.0V (Typ.)
Consumption
6/11.4W (Typ./Max.)
Signal Interface
LVDS (2 ch, 8-bit)
Interface Features :
Position
Down middle of panel
Physical Type
Connector
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Pin Assignment
UJU
PM.LVS.S040505101
0.5 mm
51 pins
1 pcs
6.BOE DV430FHM-NN1 Lightting Details
Lamp Features :
Lamp Type
WLED
Amount
-
Position
Edge light type
Exchange
-
Lamp Shape
-
Lamp Life
30K(Min.) (Hours)
Interface Features :
Position
-
Physical Type
Connector
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Pin Assignment
3.0 mm
14pins
1 pcs
Driver Electrical :
Voltage Supply
22/26V (Min./Max.)
Current Supply
3.5A (Max.)
Consumption
64W (Typ.)
7.BOE DV430FHM-NN1 Packing Details
Box/Package
Pcs/Package
Package LWH (mm)
G.W (kgs)
20
1120×1065×640
N/A
