BOE BA121S01-200 12.1" SVGA LCD Display | 800×600 TFT Screen | Industrial-Grade Panel

BOE BA121S01-200 12.1inch SVGA LCD Display
BOE BA121S01-200 12.1inch SVGA LCD Display
  • BOE BA121S01-200 12.1inch SVGA LCD Display
  • BOE BA121S01-200 12.1inch SVGA LCD Display

BOE BA121S01-200 12.1" SVGA LCD Display | 800×600 TFT Screen | Industrial-Grade Panel

Original BOE BA121S01-200 12 1-inch SVGA (800×600) TFT LCD display for industrial applications Features high reliability, wide viewing angles, and robust performance Ideal for HMI, medical devices, and industrial control systems

Model BA121S01-200
Brand BOE
Size 12.1inch
Resolution 800*600
Brightness 400 cd/m² (Typ.)
Perspective 80/80/65/75 (Typ.)
Interface LVDS
Operating Temp -20 ~ 70 °C
Production State In Production
Click For Price

1.BOE  BA121S01-200 Application Details

Basic Detail :Panel BrandBOEModel Name BA121S01-200
Panel Typea-Si TFT-LCD , LCMAnother Name
Panel Size12.1”Designed ForIndustrial
Maximum Ratings :OP Temperature-20 ~ 70 °CST Temperature-30 ~ 80 °C
RoHSRoHSVibration Level
Features :WLED Backlight，With LED Driver,Upside I/F, 180°Reverse，6/8bit


2.BOE  BA121S01-200 Optical Details

Basic Information :Luminance400  cd/m² (Typ.)Contrast Ratio800:1 (Typ.) (Transmissive)
Good View at12 o'clockResponse Speed30 (Typ.)(Tr+Td) (ms)
Viewing Angle80/80/65/75 (Typ.)(CR≥10)Operating ModeTN, Normally White, Transmissive
Color Performance :ChromaticityWx:0.313; Wy:0.329Display Colors262K/16.7M (6-bit / 6-bit + FRC)
Color Temperature6485KWhite Variation1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt :NTSC Ratio55%sRGB77% coverage
Adobe RGB57% coverageDCI-P357% coverage
Rec.202041% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)


3.BOE  BA121S01-200 Mechanical Details

Pixel Features :Number of Pixel800(RGB)*600 [SVGA]ArrangementRGB Vertical Stripe
Dot Pitch0.1025*0.3075 mm (H*V)Pixel Pitch (W*H)0.3075*0.3075 mm (H*V)  [82PPI]
Physical Size :Active Viewing(mm)246*184.5 mm (H*V)Bezel Area (mm)249.05(W)*188.30(H) mm
Outline Dim. (mm)279*209 mm (H*V)Outline Depth5.73/9.3 (Typ./Max.) mm
Outline Features :Form StyleFlat RectangleOutline Shape
Aspect Ratio4:3 (H:V)OrientationLandscape type
Holes & Brackets :Face mounting holes (6-Φ3.4) on left, right bezel
Other Features :Weight500g (Max.)SurfaceClear


4.BOE  BA121S01-200 Electronics Details

Frame Frequency :60Hz
Reverse Scan :Yes (180°)
Total Consumption :TBD


5.BOE  BA121S01-200 Interface Details

Signal Systerm :LVDS (1 ch,6/ 8-bit)
Signal Electrical :Voltage Input3.3V (Typ.)Current Input340/390mA (Typ./Max.)
Consumption0.4/0.45W (Typ./Max.)
Interface Features :PositionRearPhysical TypeConnector
Interface Detail :BrandModelPin PitchPinsAmountPin Assignment
STMMSB240420E1.25mm20pins1 pcsLVDS-20P1C8B-080B


6.BOE  BA121S01-200 Backlight Details

Lamp Features :Lamp TypeWLEDQuantity-PositionEdge light type
Exchange
-		Lamp Shape-Lamp Life30K(Min.) (Hours)
Interface Features :Position-Physical TypeConnector
Lamp DriverWith LED Driver
Interface Detail :BrandModelAmountPin PitchPin AmountPin Assignment
STMMSB24038P51 pcs1.25 mm5 pins
Driver Electrical :Voltage Input12.0±0.5VCurrent Input-


7.BOE  BA121S01-200 Carton Details

Package Carton :AmountNet WeightCarton Size (L*W*H)
8 pcs / box-375*280*290 mm
