1、AUO G156HAT01 4 Application DetailsBasic Info :Panel BrandAUOPanel ModelG156HAT01 4Diagonal Size15 6 "ApplicationIndustr
| Model | G156HAT01.4 |
| Brand | AUO |
| Size | 15.6inch |
| Resolution | 1920*1080 |
| Brightness | 420 cd/m² (Typ.) |
| Perspective | 89/89/89/89 |
| Interface | LVDS |
| Operating Temp | -20 ~ 70 °C |
| Production State | In Production |
Hangzhou IDT DISPLAY TECHNOLOGY CO.,LTD is the main agent of Youda AUO LCD screen, CHIMEI LCD screen, Mitsubishi LCD screen, INNOLUX LCD screen, Tianma LCD screen, touch LCD screen and other small ...
Read More
Price: Contact for latest real-time quotation. Final pricing depends on quantity, specification, customization requirements and exchange rate. MOQ: 1 piece.
Send your required quantity, application, delivery destination and technical requirements. Our display specialists will reply with availability and a suitable solution.
Request a Quote
1、AUO G156HAT01.4 Application Details
Basic Info :
Panel Brand
AUO
Panel Model
G156HAT01.4
Diagonal Size
15.6"
Application
Industrial
Panel Type
a-Si TFT-LCD , LCM
Model Alias
-
Reliability :
Operating Temp.
-20 ~ 70 °C
Storage Temp.
-20 ~ 70 °C
RoHS State
RoHS
Vibration Level
-
Specific Features :
With Touch, WLED Backlight，Life≥50k hours
2、 AUO G156HAT01.4 Mechanical Details
Pixel Features :
Pixel Format
1920(RGB)×1080 [FHD]
Dot Pitch
0.05975×0.17925 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.17925×0.17925 mm (H×V) [141PPI]
Mechanical Size :
Display Area (mm)
344.16×193.59 mm (H×V)
Bezel Area(mm)
-
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
16:9 (H:V)
Shape Style
Touch Panel :
Touch Points
-
Touch Panel
PCAP, Air Bonding
3、AUO G156HAT01.4 Optical Details
Basic Information :
Brightness
420 cd/m² (Typ.)
Contrast Ratio
800:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Optical Mode
AHVA, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
25 (Typ.)(Tr+Td) ms
Color Performance :
Chromaticity
X:0.313; Y:0.329
Color Numbers
16.7M (8-bit)
Color Temperature
6485K
Uniformity
1.25/1.33 (Typ./Max.)(9 points)
4、AUO G156HAT01.4 Electronics Details
Frame Frequency :
60Hz
Reverse Scan :
No
5、AUO G156HAT01.4 Backlight Details
Back-light Features :
Lamp Type
WLED
Amount
-
Life Time
50K(Typ.) (Hours)
Replacement
-
Lamp Shape
-
Position
Edge light type
Interface Features :
Type
Included in signal interface
Position
-
Lamp Driver
-
6、AUO G156HAT01.4 Interface Detail
Signal Systerm :
LVDS (2 ch, 8-bit)
Logic Voltage
-
Signal Electrical :
Voltage Input
3.3V (Typ.)
Current Input
-
Interface Features :
Type
Connector
Position
-
