AUO G150XAN02.1 15" XGA LCD Panel | 300nits, LVDS 30pin | Wide Temp Industrial Display

G150XAN02.1
G150XAN02.1
  • G150XAN02.1
  • G150XAN02.1

AUO G150XAN02.1 15" XGA LCD Panel | 300nits, LVDS 30pin | Wide Temp Industrial Display

Original AUO G150XAN02 1 15-inch TFT LCD panel: 1024x768 resolution, 800nits Hight brightness, LVDS 30-pin interface, -20°C to 75°C, and 1000:1 contrast Factory-new industrial-grade display for ATMs, HMIs, and medical devices Request datasheet & bulk pricing

Model G150XAN02.1
Brand AUO
Size 15inch
Resolution 1024*768
Brightness 800cd/m2
Perspective 89/89/89/89
Interface LVDS
Operating Temp -20 ~ 75 °C
Production State In Production
Click For Price

1.AUO  G150XAN02.1 Application Details

Basic Detail :ManufacturerAUOModel NameG150XAN02.1
Panel Typea-Si TFT-LCD , LCMModel Alias
Panel Size15inchDesigned ForIdustrial
Maximum Ratings :OP Temperature-20 ~ 75 °C  ST Temperature-20 ~75  °C
RoHSRoHSVibration Level1.5G (14.7 m/s²)
Features :Hight Brightness， WLED Backlight，Life>=50K hours,With LED Driver,Upside I/F，Matt


2.AUO  G150XAN02.1 Optical Details

Basic Information :Luminance800 cd/m² (Typ.)Contrast Ratio1000:1 (Typ.) (Transmissive)
Good View atSymmetryResponse Speed25 (Typ.)(Tr+Td) ms
Viewing Angle89/89/89/89 (Typ.)(CR≥10)Operating ModeAHVA, Normally Black, Transmissive
Color Performance :ChromaticityWx:0.313; Wy:0.329Support Color16.2M (6-bit + FRC)
Color Temperature6485KWhite Variation1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt :NTSC Ratio60%sRGB78% coverage
Adobe RGB62% coverageDCI-P362% coverage
Rec.202045% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)


3.AUO  G150XAN02.1 Mechanical Details

Pixel Features :Number of Pixel1024(RGB)*768, XGAArrangementRGB Vertical Stripe
Dot Pitch(W*H)0.099*0.297 (H*V)Pixel Pitch(W*H)0.297*0.297 (H*V)  [85PPI]
Physical Size :Active Viewing(mm)304.128(H) *228.096(V)Outline Dim.(mm)326.5(H) *253.5(V)
Bezel Area(mm)309.9(W)*236.36(H) mmDepth(mm)9.0 (Max.) mm
Outline Features :Form StyleFlat RectangleOutline Shape
Aspect Ratio4:3 (H:V)OrientationLandscape type
Mounting :Side mounting holes (4-M2) on left, right bezel
Other Spec :Weight920g (Max.)TreatmentAntiglare, Hard coating (3H)


4.AUO  G150XAN02.1 Electronics Details

Refresh Rate :60Hz
Reverse Scan :No
Total Consumption :12.13W (Typ.)


5.AUO  G150XAN02.1 Interface Detail

Signal Electrical :Voltage Supply3.3V (Typ.)Current Supply420/510mA (Typ./Max.)
Consumption1.39/1.68W (Typ./Max.)Signal InterfaceLVDS (1 ch, 8-bit)
Interface Features :PositionRearTypeConnector
Interface Detail :BrandModelPitchPinsQuantityPin Configuration
STMMSB240420HD1.25 mm20 pins1 pcs


6.AUO   G150XAN02.1 Backlight Details

Lamp Features :Lamp TypeWLEDQuantity-PositionEdge light type
Exchange
No		Lamp Shape-Lamp Life50K(Min.) (Hours)
Interface Features :Position-Physical TypeConnector
Interface Detail :BrandModelPitchPinsQuantityPin Configuration
E&T3808K-F05N-12R1.25 mm5 pins1 pcs
Backlight Driver :With LED Driver
Driver Electrical :Voltage Supply12.0±1.2VCurrent Supply0.90/0.98A (Typ./Max.)
Consumption10.74/11.78W (Typ./Max.)


7.AUO G150XAN02.1 Packing Details

Package Box :AmountSize (L*W*H)Weight
20pcs / box430*370*350 mm20.0 Kgs
